Prefabricated Outdoor Athletics Track Surface Synthetic Running Track Surface

Prefabricated Outdoor Athletics Track Surface Synthetic Running Track Surface

Prefabricated Outdoor Athletics Track Surface Synthetic Running Track Surface
Prefabricated Outdoor Athletics Track Surface Synthetic Running Track SurfacePrefabricated Outdoor Athletics Track Surface Synthetic Running Track SurfacePrefabricated Outdoor Athletics Track Surface Synthetic Running Track SurfacePrefabricated Outdoor Athletics Track Surface Synthetic Running Track SurfacePrefabricated Outdoor Athletics Track Surface Synthetic Running Track Surface
CategoriesOutdoor Athletics Track Surface
BrandNOVOTRACK
ModelNTTR-13
ColorBlue and various color
Weight13.8kg/㎡
MaterialNatural rubber
Length15m
Width1.22m
Thickness13mm
PackageRoll
BrandNovoTrack
Download
Update TimeDec 24,2024
Detail Information
Outdoor Athletics Track Surface Details
The track features a 13mm thickness, with a 4mm blue wear-resistant top layer and a 9mm gray elastic bottom layer. Both the top and bottom layers are embossed and molded in our factory.

The thickness can be customized between 8mm and 15mm, with a width ranging from 0.9m to 1.35m, and a length of 10m to 19m.
synthetic surfaces features
Professional Athletic Track and Field Floor
Prefabricated rubber athletic track surfaces are globally recognized as an ideal replacement for traditional polyurethane (PU) tracks. Their one-time embossing process ensures exceptional quality, offering advantages such as strong wear resistance, anti-slip properties, shock absorption, excellent elasticity, anti-aging characteristics, and long-lasting durability. Additionally, they eliminate the issue of rubber granules detaching from the surface. These tracks are fully recyclable at the end of their lifespan and have successfully passed IAAF tests, certifying them as environmentally friendly products.
pro athletics track
Installation
NovoTrack has a well trained professional installation team which has 17 years of experiences for the stadium construction of Olympic Games and National Games.We provide the most suitable project according to the requirements of every individual customer and field.We provide free installation instructions. If necessary, we provide on-site installation training services. Help you become more competitive in your market.
athletics track after-sale service
running track installation

1. The foundation should be smooth enough and without sand. Grinding and leveling it. Be sure it does not exceed±3mm when measured by 3m straightedges.

running track installation

2. Follow the daily construction plan to place the prefabricated rubber running track in the designated location. Draw the baseline according to the provided drawing.

running track installation

3. Stir the adhesive as required which will be used within one hour

running track installation

4. Take the stirred glue to the required area, scratch the glue 2-3 meters equably with toothed scrapers.

running track installation

5. Put the rubber roll materials on the fixed po sition,unfold it to be connected with adhesive.

running track installation

6. Use a special trowel to forcefully flatten the running track surfaces.

Eliminate the air bubbles remaining in the bonding process of the roll and the base.

running track installation

7. The gap should be sealed with nails.

athletics track installation

8. After fixed by nails,pressed by bricks for better connection.

athletics track clean

9. Clear the athletics track

athletics track installation

10. After completing the installation, inspect the entire field to ensure all gaps are filled with adhesive and smoothed. Finally, clean the entire field thoroughly and ensure it is kept clean.

athletics track installation

11. Mark the lines according to the provided drawings.

athletics track installation

12. Extend the straight track line, and then mark the lane numbers on the running track.

We provide better and more comfortable sports environments for athletes. The primary material we use is natural rubber, and the track surfaces are constructed in two layers. The upper layer is slightly harder than the lower layer, with a waffle pattern forming 8,400 concave air cushions per square meter after being adhered to the asphalt base. This design enhances anti-slip properties, elasticity, and shock absorption, reducing the risk of injury for athletes.
Safety & Eco-friendly
The unique surface undulation and concave bottom air cushion design provide a suitable shock absorption and energy feedback system, which can effectively improve sports performance while ensuring sports safety.
The flooring does not contain any toxic heavy metals and harmful chemical substances, and its physical and chemical properties are in full compliance with national standards and environmental protection requirements. This is indeed for the physical and mental health of sports athletes. The rubber surface layer can still be recycled after its service life expires. Save land resources.
Certificates
IAAF Product Certificate
World Athletics Product Certificate
ISO 9001
ISO 9001
ISO 14001
ISO 14001
ISO 45001
ISO 45001
Tianjin NovoTrack Rubber Products Co., Ltd., established in 2004 with a total investment of 20 million RMB, specializes in manufacturing various types of sports flooring. Over the years, we have installed millions of square meters of track surfaces in city sports centers, university campuses, high schools, and other venues.

We are certified with ISO 9001, ISO 14001, and ISO 45001 standards, ensuring quality, environmental responsibility, and occupational health and safety.

NovoTrack is proud to be the supplier for the 11th, 12th, 13th, and 14th China National Games.

Our prefabricated rubber track surface is also certified by World Athletics, meeting the highest standards for performance and safety.
NovoTrack Team
NovoTrack team
Common Questions
What are the dimensions of a 400m running track?
400m Running Tracks have an overall length 580'5'' | 176.91 m, an overall width of 303'6'' | 92.5 m, and a total area of roughly 157,092 ft2 | 14,594 m2.
Standard 400-meter running track layout
Standard 400-meter running track layout
